JINPAT Pancake Slip Ring - 14mm ultra-thin breakthrough, high-definition signal transmission

Facing the dual challenges of equipment miniaturization and functional complexity, traditional connection methods often become a bottleneck. The development of the JINPAT LPK series pancake slip rings aims to solve this critical problem: "How to achieve continuous and stable 360-degree transmission of power and high-definition signals (especially video signals) in extremely limited space," thus opening up new possibilities for automated equipment design.

Two core technological advantages and applications:

Advantage 1: Reliable high-definition video signal transmission channel

This slip ring integrates a transmission channel optimized for video signals, supporting various formats such as HDMI and Camera Link.

Application: This makes it the "nerve center" of rotating vision systems, online inspection equipment, and monitoring PTZ systems, allowing the mechanical "eyes" to maintain a clear and stable "field of view" during rotation.

Advantage 2: 14mm ultra-thin design for a spatial revolution

Its flat structure compresses the installation height to 14 millimeters, allowing for easy integration into the confined spaces of equipment.

Application: This saves valuable structural space for applications that are extremely sensitive to space limitations (such as collaborative robot joints, precision rotary tables, and semiconductor processing equipment), directly contributing to smaller and more integrated equipment designs.

In short, the JINPAT LPK series pancake slip ring is not just a connecting component; it is a practical and ingenious engineering solution that effectively solves the traditional dilemma of achieving both high performance and compactness.

Call to action:

If you are looking for the best solution for signal transmission and spatial layout of your equipment's rotating parts, the JINPAT LPK series is a trustworthy choice. Please contact our technical team for customized selection support.
