Application of JINPAT gas-liquid-electric integrated slip ring in automatic lithium liquid separator

With the development of electricity, the global lithium battery industry has been rapidly rising. Most companies in the industry have increased their investment and allocated a large number of automatic lithium battery processing machines. As an indispensable part of automatic machinery, slip rings also appear in many equipments in the lithium battery manufacturing industry.

As a leading international slip ring manufacturer, JINPAT has developed thousands of slip ring products for the automation industry, including products developed by the lithium battery industry. Among the products developed by JINPAT for the lithium battery industry, there are many types of integrated slip rings that operate with gas, liquid and electricity.

The integrated slip ring for gas, liquid and electricity is composed of a conductive slip ring and a gas-liquid slip ring. Generally speaking, the conductive slip ring is responsible for transmitting electricity and the gas-liquid slip ring is responsible for transmitting compressed gas. The two units are processed independently and then connected together by screws.

Representative product models of JINPAT include LPT000-3205-06A, LPT000-3201-16A, LPT000-3205-48S-16A. These models are all applicable to lithium automatic liquid separator. From the point of view of electrical parameters, they are typical products with common characteristics. For example, their conductive slip ring module has 32 current paths, and the supported currents are 1A and 5A. The current path of these products has the ability to support mixed signal and current transmission. However, it can only be used with some terminals that do not require signal transmission requirements. When the number of conductive slip rings is relatively small and the terminal equipment needs more signal channels, it is necessary to add special signal modules in the conductive slip rings. LPT000-3205-48S-16A is a typical representative of this product. The conductive slip ring module of this product integrates 32 5A current paths and 48 signal paths. The liquid gas unit is a 16-way compressed air unit. According to the number of channels of the liquid gas slip ring unit of these products, the size of the terminal equipment can be estimated, so the terminal equipment LPT000-3201-16A LPT000-3205-48S- 16A is a relatively large and efficient filling equipment.

As a well-known manufacturer in the international link industry, the technical strength of JINPAT is certainly beyond doubt. JINPAT has integrated the products required to develop various business technology for lithium battery manufacturing.
