LM Standard Pneumatic Rotary Unions
LM Standard Pneumatic Rotary Unions
LM Standard Pneumatic Rotary Unions
LM Standard Pneumatic Rotary Unions

LM Standard Pneumatic Rotary Unions

The LPP rotary unions can perform rotation of 360 degrees. The medium includes inert gas such as compressed air

Product Details

The LPP rotary unions can perform rotation of 360 degrees. The medium includes inert gas such as compressed air, steam, vacuum, nitrogen, hydrogen, etc. It can integrate slip ring to transport various control signals. The sealing surface and sealing ring are made of special materials, with the advantages of wear resistance, long life, corrosion resistance, and no leakage. Customers can install LPP rotary unions independently according to the application environment.


LM Standard Pneumatic Rotary Unions
Model Code Passages(Gas/Flow) Medium Size
Joint thread Flow Orifice
 LPPA-LM0101 1 in 1 out Air, Vacuum Φ40*Φ6*41 M5
Φ3
 LPPA-LM0201 2 in 2 out Air, Vacuum Φ40*Φ6*50 M5 Φ3
 LPPA-LM0401 4 in 4 out Air, Vacuum Φ40*Φ6*68 M5 Φ3
 LPPA-LM0601 6 in 6 out Air, Vacuum Φ40*Φ6*86 M5 Φ3
 LPPA-LM0801 8 in 8 out Air, Vacuum Φ40*Φ6*104 M5 Φ3
 LPPA-LM1001 10 in 10 out Air, Vacuum Φ40*Φ6*123 M5 Φ3
 LPPA-LM01201 12 in 12 out Air, Vacuum Φ40*Φ6*156 M5 Φ3
 LPPA-LM01601 16 in 16 out Air, Vacuum Φ40*Φ6*201 M5 Φ3
 LPPA-LM02401 24 in 24 out Air, Vacuum Φ40*Φ6*307 M5 Φ3
