LPA000-034000 Large Volume Series Slip Rings
Unique triangle base design to specifically applicable for operation in swaying and tilting movement condition like vessels or ships.
A slip ring can be used in any electromechanical system that requires unrestrained, continuous rotation while transferring power or data from a stationary to a rotating structure. A slip ring is also called a rotary electrical interface, collector, swivel or a commutation. A slip ring can improve system performance by simplifying operations and eliminating damage-prone wires dangling from movable joints.
Electronic & Electric |
Mechanical |
|||
| Circuits | Total | 137CKT |
Working Speed |
0~3RPM |
| Detail | 3*4000A+1*400A+3*8A+2*3A+54*250MA+18*0.3A+38*signal+12*The standby |
A hole diameter |
/ |
|
Rating Voltage |
690VAC/340V/220VAC/30V/24V | Contact Material |
High-end Copper Graphite /Precious Metal |
|
Dielectric Strength |
2500VAC@60Hz(P) |
Housing |
Q235 Spray Coating(RAL 7032) |
|
Insulation Resistance |
≥500MΩ@1000VDC(P) ≥100MΩ@300VDC(S) |
Installation |
/ | |
Environment |
Remarks |
|||
Working Temperature |
-10°C~+50°C |
Application |
/ |
|
Working Humidity |
≥95%RH |
|||
IP |
IP54 |
Other |
/ | |
For more customized solutions, please feel free to contact us at any time!
