LPA000-06405 Large Volume Series Slip Rings
LPA000-06405-06PE-03100-01PE-0616-02PE-0910-03PE is a integrated slip ring specially designed for helicopter equipment testing platform.
LPA000-06405-06PE-03100-01PE-0616-02PE-0910-03PE
is a integrated slip ring specially designed for helicopter equipment testing platform. This slip ring is installed in the testing platform to test the related performances of a helicopter while large angle pitching and rolling. JINPAT slip ring has edge-cutting technology in the field.
We ensure our client to receive slip ring products of superior quality.
Electronic & Electric |
Mechanical |
|||
| Circuits | Total | 36CKT |
Working Speed |
0~20RPM |
| Detail | / |
A hole diameter |
/ |
|
Rating Voltage |
380VAC | Contact Material | / |
|
Dielectric Strength |
500VAC@50Hz |
Housing |
/ |
|
Insulation Resistance |
≥500MΩ@1000VDC |
Installation |
/ |
|
Environment |
Remarks |
|||
Working Temperature |
≤-10°C~+55°C |
Application |
/ |
|
Working Humidity |
≥95%RH |
|||
IP |
IP55 |
Other |
/ | |
For more customized solutions, please feel free to contact us at any time!
