LPA000-03300 Large Volume Series Slip Rings
This is a marine crane slip ring.
This is a marine crane slip ring. Power capacity and channel number are optional.
Can integrate with signal module, pneumatic/hydraulic module and multi-channel fiber optic rotary joints.
Optional protection grading and explosion-proof grading.
Electronic & Electric |
Mechanical |
|||
| Circuits | Total | 25CKT |
Working Speed |
0~10RPM |
| Detail | 3*300A+1*PE+3*50A+2*10A+16*signal |
A hole diameter |
/ |
|
Rating Voltage |
690VAC/380VAC/220VAC | Contact Material |
High-end Copper Graphite /Precious Metal |
|
Dielectric Strength |
2000VAC@50Hz(P) |
Housing |
Q235 Spray Coating(RAL 7032) |
|
Insulation Resistance |
≥1000MΩ@1000VDC(P) ≥500MΩ500VDC(S) |
Installation |
Vertical Installation |
|
Environment |
Remarks |
|||
Working Temperature |
-10°C~+45°C |
Application |
Marine Crane |
|
Working Humidity |
≥95%RH |
|||
IP |
IP44 |
Other |
/ | |
For more customized solutions, please feel free to contact us at any time!
