LPT000-0508-E2-01A Through Bore Slip Rings

LPT000-0508-E2-01A- Through hole slip ring

The LPT000-0508-E2-01A is a through-hole integrated slide ring.This model is a high-precision conductive slide ring that integrates electrical signals and Ethernet signals. It adopts special structural design and advanced manufacturing technology that allows integrated transmission of upstream and Ethernet signals in the slip ring, making them independent of each other without any interference. This slip ring is a weak electric slip ring with an operating voltage of 24V. There are 5 8A power channels, one 100M Ethernet channel, and one air/hydraulic channel. This slip-through socket uses gold-to-gold contacts, with a protection rating of IP65. Both the stator and the rotor use a special interface instead of wire connections. With unique structure, this slip ring has excellent electrical performance.

LPT000-0508-E2-01A  Outline Drawing
