Advantages
◆ Unique signal handling performance with minimal electrical noise
◆ Compact design to fit the most demanding space
◆ Low torque reduces the system torque budget
◆ Fast delivery
Main applications
◆ Packaging/packaging machines
◆ Semiconductor handling systems
◆ Industrial machinery
◆ Display machines display
◆ Medical equipment
◆ Rotary index tables
◆ Process control equipment
◆ Emergency lighting, robotics palletizing machines,
◆ Heavy equipment towers or cable reels
Electronic & Electric |
Mechanical | |||
Circuits |
Total |
6 CKT |
Working Speed |
0~300rpm |
Detail |
5A |
Inner Diameter |
∅150mm |
|
Rating Voltage |
240VAC/DC |
Contact Material |
Precious Metal |
|
Dielectric Strength |
1000VAC@50Hz |
Shell Material |
Aluminum alloy |
|
Insulation Resistance |
≥500MΩ@500VDC |
Lead Wire Length |
Stator:300mm Rotor:300mm |
|
Environment |
Remarks | |||
Working Temperature |
-20°C~+60°C |
Application |
/ |
|
Working Humidity |
≤60%RH |
Other |
/ |
|
IP |
IP54 |
Note: "P" stands for power, "S" stands for signal. |
||
